# What’s the difference between R-Value and U-value?

U-value and R-value are methods of measuring energy efficiency. They are both used to determine the thermal performance of a building. U-values use a scientific calculation to measure the level of heat transfer through a window. R-value measures the insulating capacity of a specific material and its capacity for heat transfer reduction.

## U-values – essential information

U-value calculates the insulating performance of a window unit. This includes the glass, frame and air gaps. It is used across the glazing industry to determine the energy efficiency performance of windows. U-values are measured in watts per square metre per kelvin (W/m²K). U-value can also be used to:

• Measure thermal efficiency
• Measure insulating capacity
• Indicate heat transfer levels
• Measure airflow
• Measure reflected or radiated heat

U-values are measured using a scientific calculation which determines the rate that heat flows through one square foot of the window. This shows how well a window prevents heat from escaping from a building interior.

## What is a good U-value?

U-values are measured on a scale where the lower the number, the better the product at preventing heat loss. Part L of current Building Regulations legislation (mandatory from June 2022) states that a standard window replacement should have a U-value no higher than 1.6 W/m²K for new dwellings and 1.4 W/m²K for existing dwellings. For doors, the required minimum U-value is slightly higher at 1.8 W/m²K.

To provide some context for what a good U-value is, the following information can be helpful to compare materials and their U-values.

 Product/material Average U-value Single glazed window 5.0 W/m²K Double glazed window 1.6 W/m²K Triple glazed window 0.8 W/m²K Solid wall 0.3 W/m²K Roof 0.16 W/m²K Ground floor 0.22 W/m²K

## R-values – essential information

While U-values measure the amount of heat which is transferred through a material, R-values focus on the material’s property value. R-values are often used to find out a material’s insulating capacity. R-values are based on the conduction and resistance of a material to heat transfer. The higher the R-value, the better the material is at insulating and resisting heat transfer. R-values can help us to understand a material’s:

• Energy efficiency performance
• Insulating capacity
• Heat resistance

Although R-values are generally used to understand the thermal performance of different types of building materials, they are also an important part of calculating a window unit’s overall energy efficiency capacity.

## How do R-values affect a window’s energy efficiency rating?

As mentioned above, R-values calculate the thermal performance of a specific material. When assessing a window’s R-value, all material’s performance values must be considered. Whereas U-values only refer to heat transfer through the sealed window unit itself, R-values evaluate the material performance of all other parts of the window including:

• The caulking and sealant used
• The area where the window meets the wall
• Any trims, edging and ancillary components

R-values and U-values are closely linked. If you know the U-value of a window, then you can calculate its R-value and vice versa. To do this the following formulas can be used:

Convert U-value to R-value – divide 1 by U-value eg. U-value = 0.10, 1 ÷ 0.10 = 10

Convert R-value to U-value – divide 1 by R-value eg. R-value = 3.45, 1 ÷ 3.45 = 0.29

These are mathematical reciprocals, and the measurements are determined by the original calculation.

## How can U-values be improved?

To ensure that windows meet the required levels for energy efficiency performance, there are several ways to improve a window’s U-value. It’s important to consider U-values in two ways. Summer daytime U-values measure how well a window blocks solar gain to retain an ambient interior temperature. Winter night-time U-values measure a window’s heat retention capacity.

To improve a window’s U-values you can:

• Always specify double or triple glazed Insulated Glass Units (IGUs)
• Used a noble gas such as argon or krypton in the space between the glass panes in the sealed unit
• Increase the size of the space between the glass panes
• Use warm edge spacer bars to create an effective thermal barrier (this is particularly useful in aluminium windows)
• Use low emissivity (Low E) coatings to reduce emissivity and improve reflectance of thermal energy

Understanding the importance of both U-values and R-values is an essential part of window manufacturing and installation. At Exlabesa, we manufacture and supply a range of high performing glazing systems for trade installers.
